Full Jacketed Disc Check Valve

Jket® brand Jacketed Spring-Loaded Disc Check Valves, also known as Spring Loaded Jacketed Non-Return Valves, boast a compact and robust wafer type design crafted from either durable corrosion-resistant Stainless Steel (ASTM A 351 GR. CF8/CF8M/CF3/CF3M/SS304/SS316/SS304L/SS316L). These valves are versatile, suitable for a wide array of applications handling process liquids, air, gases, and steam. It can be installed in vertical and horizontal both lines.

Comprising five key elements - the body, disc, jacket, star guide, and spring - the Full Jacketed Dual Plate Non-Return Valve operates efficiently. When fluid pressure is applied, the valve opens, and upon flow cessation, the compression spring promptly shuts it down, effectively preventing any reverse flow.

What sets these valves apart is their innovative design, featuring a Full Jacketed, Wafer Design, Sandwich Type, and flangeless configuration. This unique construction enables easy installation between flanges of varying standards and orientations, including vertical pipelines where the fluid flows downward. This adaptability ensures seamless integration into diverse systems, promising efficient flow control and reliable prevention of backflow.

With over a quarter-century of expertise, we seamlessly integrate advanced technology, elevate quality standards, and excel in the design and development of jacketed check valves.

For the installation of a Jacketed Disk Valve, it's imperative to note that oversize flanges are necessary due to the provision of a jacket on the valve body.
