Full Jacketed Dual Plate Check Valve

Jket® brand Fully Jacketed Spring-Loaded Dual Plate Type Check Valve, also known as Jacketed Dual Disc Non-Return Valves, boast a compact and robust flangeless, wafer design check valve. These valves are versatile, suitable for a wide array of applications handling process molten sulphur, polymer, resin, bitumen, chocolate, chemical, asphalt etc. It can be installed in vertical and horizontal both lines. Each valve has by default Metal to Metal seats to sustain high pressure as well high temperature.

Comprising five key elements - the body, disc, jacket, hinge pin, and spring- the Jacketed Single Disc Check Valve operates efficiently. When fluid pressure is applied, the valve opens, and upon flow cessation, the compression spring promptly shuts it down, effectively preventing any reverse flow.

What sets these valves apart is their innovative design, featuring a Full Jacketed, Wafer Design, Sandwich Type, and Flangeless configuration. This unique construction enables easy installation between flanges of varying standards and orientations, including vertical pipelines where the fluid flows downward. This adaptability ensures seamless integration into diverse systems, promising efficient flow control and reliable prevention of backflow.

With over a quarter-century of expertise, we seamlessly integrate advanced technology, elevate quality standards, and excel in the design and development of jacketed check valves.

For the installation of a Full Jacketed Dual Plate Check Valve, it's imperative to note that oversize flanges are not required.
